Rust, let me share your awesomeness with C

Ahoy reader, this is kinda an open letter. But mostly is my desperation in computer font. Rust why don’t you love me? I read about you, I spent nights and days. I fought the borrow checker monster for you. I learned about lifetimes. And you promised two things:

  • “Systems” language, close to C
  • Memory safety

I just wanna call you via a C binary. I don’t want you to fly. I just wanna love you…

But before we get to the chase, lets get to drama. You know how I love backstories (and I’ve been watching How to get away with murder).

The story

The project that all this happend for is not a new idea to me. It boiled inside me for quite some time. I’m referring to mage I started writing it about 6 months ago, when a friend asked me for a stable tool that is able to listen for TCP shells and have TTY support for his OSCP (that’s a story for another day, for more check out netcatty). Of course I stopped whatever (another project) I was doing and started coding. I was currently into Go, so I went with it. As I was writing netcatty, first of all I lost a huge oportunity to name it netkitty which is way better and second I started spiraling out about what I could actually do. Why only TCP? I can do better!

That’s where mage was born. Mage is a tiny protocol, intended to be encapsulated inside all kinds of transports. HTTP requests, headers, cookies, TCP timestamps, DNS queries etc. What a marvelous idea!

Remember when post-exploitation toolkits & implants communicated with the C2 over TCP or HTTP? Remember when you could feel the earth shaking every time a meterpreter payload exited the final gateway of a target cause a stray UDP connection to a russian server on port 1337 just opened? Remember when the connection would get killed and your server banned after 5’ you got a shell? Well mage is willing to do its magic to stop this madness.

The blue team laughing at your windows/meterpreter/reverse_tcp

The blue team laughing at your windows/meterpreter/reverse_tcp

The idea is that you generate a binary payload (msf or whatever) and you “wrap” it using mage. By wrap I mean that the mage .so (or .dll) would be injected inside the binary and then binary patch all the socket.h (or winsock) calls to use the mage functions (spoiler: “wrapping” is not yet implemented, that’s what this post is about).

The mage primarilly does the following:

  • Connect to the C2 (completely ignoring the address that the implant wanted to connect to) over whatever protocol you set up during wrapping
  • Exchange keys with the server (libsodium)
  • Start encrypted communication with the server (libsodium)

Useful features include chunking, very low overhead, support for out-of-order packet reception (and maybe sometime packet retransmission?)

That’s all good, but I’m still talking about a Go project huh? No…

As any good project, you have to write it at least twice for it to be good. I think I maybe overdid it and rewrote it too fast. Here. I rewrote it in rust. Rust was a much better fit, as it’s much closer to the system, it doesn’t carry a GC and the overal Rust - insert-lang-here interfacing I THOUGHT was easier. If I only knew…

The target

As said, wrapping is not ready. Nor any actually useful transports. Right now the protocol, encryption/decryption, multiplexing and thread channels are ready. To start implementing wrapping, I had to create a libC API. All answers led to cbindgen, a very cool project that all it does is generate C headers, but to use it, you need to create a C API!

The “final” struct that I wanted to export was Connection (see here):

pub struct Connection<'conn> {
    pub id: u32,
    stream: Stream,
    reader: &'conn mut dyn Read,
    writer: &'conn mut dyn Write,
    channels: HashMap<u8, Vec<(Sender<Vec<u8>>, Receiver<Vec<u8>>)>>
}
impl<'conn> Connection<'conn> {
pub fn new(id: u32, reader: &'conn mut impl Read, writer: &'conn mut impl Write, server: bool, seed: &[u8], remote_key: &[u8]) -> Result<Self>
...
}
impl Read for Connection<'_> {...}
impl Write for Connection<'_> {...}

The C API has to be like that (to be in-place compatible with socket.h):

#[no_mangle]
pub unsafe extern "C" fn connect(_socket: c_int, _sockaddr: *const c_void, _address_len: c_void) -> c_int
#[no_mangle]
pub unsafe extern "C" fn send(_socket: c_int, msg: *const c_void, size: usize, _flags: c_int) -> usize
#[no_mangle]
pub unsafe extern "C" fn recv(_socket: c_int, msg: *mut c_void, size: usize, _flags: c_int) -> usize

It does not implement all the socket.h functions, but I started with the most vital ones.

This is my target, expose connect, send and recv to C and let them handle the whole logic. No mystery threads n’ stuff, it could mess a lot wit AV evasion (while it AV evasion has nothing to do with this project, I shouldn’t make it harder)

The problem

The problem that I quickly realized was that there was no way to have a “state”. I couldn’t just pass the Connection struct back & forth, as socket.h does! I have to adhere to the function signatures and if someone messes with my struct in a completely unchecked manner, anything could go wrong.

So I went on and tried to create a static object holding a Connection, that would be initialized on connect. Oh the horror…

Rust says that it needs to know the size of Connection at compile time to let me have it as static. That’s not possible. I add a reference, but it can’t live long enough so I go with Box. lazy_static enters the game. No idea what it does, but it solved a problem with static. But introduces another. No mutability. So I add a Mutex.

Right now we have this:

lazy_static! {
	static ref CONN: Mutex<Option<Box<Connection>>> = Mutex::new(None);
}

Ok, that’s fine. It compiles (nobody knows if this actually works yet). But then starts another rabbit hole. Inside connect, among other stuff I call Connection::new. Connection::new accepts reader: &'conn mut impl Read, writer: &'conn mut impl Write. And these are satisified by a TcpStream and TcpStream.try_clone.unwrap(). Now I can’t borrow these, as they’re inside the function scope.

This is the problem. I don’t know how to pass TcpStream to a new static Connection. I tried making it static as well, Boxing and Rcing them. Didn’t fucking work. If anyone can help, please do so…

My code after all the "tries"

My code after all the "tries"


I know that you don’t read this type of posts often - or I don’t often read them (ranting due to lack of skill). But this was mainly a rubber duck debugging session for me and it’s one of the very few moments that I’m so stuck, that I’m thinking about abandoning the project. Most times I just get bored or find something new. This is different. I’ve hit a brick wall and can’t find even a really dirty hack around it (even though I hate “hacky” code).

Happy Hacking!
